48 Volt – 3400 Watthours

Lithium Battery 48V 3400Wh

in stock

The elegant looks disguise a powerful lithium battery
that is truly portable, extremely durable, safe and seriously smart
with an integrated BMS and communicating app.
Ready for any adventure you take it on!

Voltage
24
Watt-Hours
1700
Amere Hours
6
Kilograms
19
IP Rating
20

All our batteries are
designed and manufactured
in The Netherlands

More information about this product?

Ask our experts, we are happy to help!

Opening hours: monday – friday from 08:30 to 17:30

Call us at

+31 6 81 28 06 24

IONBASE-500.svg

battery monitoring app

check your battery status

All round performance
The 48 Volt 3.4 kWh (66.5Ah) lithium battery is a powerful and compact battery ideal for a wide range of applications. From drive trains, auxiliary power to industrial work platforms and other industrial equipment, it is ready to power all your needs. Easy to connect and disconnect due to its flex connectors.

Robust and Built to last
Our batteries perform even in the most demanding conditions. The robust aluminium enclosure protects the battery and its electronics from shocks, vibrations, and the environment. The IP67 rating makes sure you don’t have to worry about any dust or water damage. Our batteries are truly built to last.

Safe and Reliable
Safety and reliability are top priority in every aspect of the design. The integrated battery management system (BMS) constantly monitors the battery, ensuring maximum safety and performance. Our cylindrical lithium iron phosphate technology combined with a robust aluminium enclosure makes sure the battery is as safe and reliable as possible. This keeps you and your equipment safe and full of energy at all times.

No Worries
Designed and assembled in the Netherlands to the highest quality standards. With a generous 5 year warranty, virtually zero maintenance, and long cycle life you don’t have to worry about your battery for a very long time.

IP67
Waterproof enclosure

Applications

This 48V battery can be perfectly used for wide varity of applications

Marine

Drive train and auxiliary power solutions

Golf

Drive trains for golf carts and small electric vehicles

Floor Care

Drive train and Auxiliary power solutions for floor care

Construction

Drive train and auxiliary power solutions for construction equipment

Material Handeling

Primary power for fork lifts, pallet stackers and trucks

Work platforms

Primary power Mobile elevated work platforms

Your application not listed?

Our batteries are very versatile, if you need more information for usage in a different application, or you are in need of specialized energy storage systems, please do not hesitate to contact us.

Battery Specifications

General features
Battery12V 1700Wh12V 3400Wh24V 3400Wh24V 6800Wh48V 3400Wh48V 6800Wh48V 13600Wh
Nominal energy capacity1700 Wh3400 Wh3400 Wh6800 Wh3400 Wh6800 Wh13600 Wh
Nominal capacity133 Ah266 Ah133 Ah266 Ah66.5 Ah133 Ah266 Ah
Useable capacity129 Ah258 Ah129 Ah258 Ah65 Ah129 Ah258 Ah
Capacity @25A310 min620 min310 min620 min155 min310 min620 min
Nominal voltage12,8 V12,8 V25,6 V25,6 V51,2 V51,2 V51,2 V
Charging voltage14,2 V14,2 V28,4 V28,4 V56,8 V56,8 V56,8 V
Discharging voltage10,8 V10,8 V21,6 V21,6 V43,2 V43,2 V43,2 V
Continuous discharge rate150 A150 A150 A150 A100 A150 A150 A
Max quick charge80 A130 A80 A130 A60 A80 A130 A
Max peak discharge rate (2s)300 A400 A300 A400 A200 A300 A400 A
Max peak discharge rate (10s)200 A300 A200 A300 A150 A200 A300 A
Weight19 kg34 kg34 kg61 kg33 kg61 kg119 kg
Length (+- 5mm)242 mm392 mm392 mm695 mm397mm695 mm1295 mm
Width (+- 2mm)253 mm253 mm253 mm253 mm253 mm253 mm253 mm
Height exluding feet (+- 2mm)212 mm212 mm212 mm212 mm212 mm212 mm212 mm
Square shape volume13 L21 L21 L37 L21 L37 L69 L
Height including feet227 mm227 mm227 mm227 mm227 mm227 mm227 mm
Battery12V 1700Wh12V 3400Wh24V 3400Wh24V 6800Wh48V 3400Wh48V 6800Wh48V 13600Wh
Ambient temperature discharging-18 up to 55 °C-18 up to 55 °C-18 up to 55 °C-18 up to 55 °C-18 up to 55 °C-18 up to 55 °C-18 up to 55 °C
Ambient temperature charging-2 up to 45 °C-2 up to 45 °C-2 up to 45 °C-2 up to 45 °C-2 up to 45 °C-2 up to 45 °C-2 up to 45 °C
Ambient temperature storage-25 up to 55 °C-25 up to 55 °C-25 up to 55 °C-25 up to 55 °C-25 up to 55 °C-25 up to 55 °C-25 up to 55 °C
Typical storage time at 50% SOC40 weeks40 weeks40 weeks40 weeks40 weeks40 weeks40 weeks
Max connectionsUp to 1S8PUp to 1S8PUp to 2S8PUp to 2S8PUp to 1S8PUp to 1S8PUp to 1S8P
Protection class (exl. Salt water)IP67IP67IP67IP67IP67IP67IP67
Battery12V 1700Wh12V 3400Wh24V 3400Wh24V 6800Wh24V 6800Wh48V 6800Wh48V 13600Wh
Cell typeCylindricalCylindricalCylindricalCylindricalCylindricalCylindricalCylindrical
ChemistryLiFePo4LiFePo4LiFePo4LiFePo4LiFePo4LiFePo4LiFePo4
Capacity per cell6,05 Ah6,05 Ah6,05 Ah6,05 Ah6,05 Ah6,05 Ah6,05 Ah
Nominal voltage per cell3,2 V3,2 V3,2 V3,2 V3,2 V3,2 V3,2 V
Cell configuration4s22p4s44p8s22p8s44p16s11p16s22p16s44p
Battery12V 1700Wh12V 3400Wh24V 3400Wh24V 6800Wh48V 34004848V 6800Wh48V 13600Wh
On-off switchYesYesYesYesYesYesYes
TerminalsM8 screw FM8 screw FM8 screw FM8 screw FFlexFlexFlex
Cell balancing, passiveYesYesYesYesYesYesYes
High current & short circuit protectionYes, up to 1500AYes, up to 1500AYes, up to 1500AYes, up to 1500AYes, up to 1500AYes, up to 1500AYes, up to 1500A
Deep discharge protectionYesYesYesYesYesYesYes
Protection against polarity reversalYesYesYesYesYesYesYes
Individual cell string voltage monitoringYesYesYesYesYesYesYes
Safety vent for each cellYesYesYesYesYesYesYes
Cell temperature monitoringYesYesYesYesYesYesYes
Temp. monitoring battery electronicsYesYesYesYesYesYesYes
Shipping classificationUN3480, CLASS 9UN3480, CLASS 9UN3480, CLASS 9UN3480, CLASS 9UN3480, CLASS 9UN3480, CLASS 9UN3480, CLASS 9
Certifications/compliance batteryCE, UN38.3, RoHSCE, UN38.3, RoHSCE, UN38.3, RoHSCE, UN38.3, RoHSCE, UN38.3, RoHSCE, UN38.3, RoHSCE, UN38.3, RoHS
Certifications/compliance battery cellsUL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3UL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3UL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3UL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3UL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3UL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3UL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3
Battery12V 1700Wh12V 3400Wh24V 3400Wh24V 6800Wh48V 3400Wh48V 6800Wh48V 13600Wh
Cycle lifetime with 80% discharge depth at 25°C to capacity loss of 20% at 0.5C>4000>4000>4000>4000>4000>4000>4000
Average annual capacity loss at 25 °C2%2%2%2%2%2%2%
Ideal storage temperature-10 up to 30 °C-10 up to 30 °C-10 up to 30 °C-10 up to 30 °C-10 up to 30 °C-10 up to 30 °C-10 up to 30 °C
