12 Volt – 1700 Watthours

Lithium Battery 12V 1700Wh

1.350

In stock

M8 Bolt connectors

easy and convenient

Original Black

available and black and gold edition

Battery Specifications

General features
Battery12V 1700Wh12V 3400Wh24V 3400Wh24V 6800Wh48V 6800Wh48V 13600Wh
Nominal energy capacity1700 Wh3400 Wh3400 Wh6800 Wh6800 Wh13600 Wh
Nominal capacity133 Ah266 Ah133 Ah266 Ah133 Ah266 Ah
Useable capacity129 Ah258 Ah129 Ah258 Ah129 Ah258 Ah
Capacity @25A310 min620 min310 min620 min310 min620 min
Nominal voltage12,8 V12,8 V25,6 V25,6 V51,2 V51,2 V
Charging voltage14,2 V14,2 V28,4 V28,4 V56,8 V56,8 V
Discharging voltage10,8 V10,8 V21,6 V21,6 V43,2 V43,2 V
Continuous discharge rate150 A150 A150 A150 A150 A150 A
Max quick charge80 A130 A80 A130 A80 A130 A
Max peak discharge rate (2s)500 A500 A500 A500 A500 A500 A
Max peak discharge rate (10s)400 A400 A400 A400 A400 A400 A
Weight19 kg34 kg34 kg61 kg61 kg119 kg
Length (+- 5mm)242 mm392 mm392 mm695 mm695 mm1295 mm
Width (+- 2mm)253 mm253 mm253 mm253 mm253 mm253 mm
Height exluding feet (+- 2mm)212 mm212 mm212 mm212 mm212 mm212 mm
Square shape volume13 L21 L21 L37 L37 L69 L
Height including feet227 mm227 mm227 mm227 mm227 mm227 mm
Battery12V 1700Wh12V 3400Wh24V 3400Wh24V 6800Wh48V 6800Wh48V 13600Wh
Ambient temperature discharging-18 up to 55 °C-18 up to 55 °C-18 up to 55 °C-18 up to 55 °C-18 up to 55 °C-18 up to 55 °C
Ambient temperature charging-2 up to 45 °C-2 up to 45 °C-2 up to 45 °C-2 up to 45 °C-2 up to 45 °C-2 up to 45 °C
Ambient temperature storage-25 up to 55 °C-25 up to 55 °C-25 up to 55 °C-25 up to 55 °C-25 up to 55 °C-25 up to 55 °C
Typical storage time at 50% SOC40 weeks40 weeks40 weeks40 weeks40 weeks40 weeks
Max connectionsUp to 1S8PUp to 1S8PUp to 2S8PUp to 2S8PUp to 1S8PUp to 1S8P
Protection class (exl. Salt water)IP67IP67IP67IP67IP67IP67
Battery12V 1700Wh12V 3400Wh24V 3400Wh24V 6800Wh48V 6800Wh48V 13600Wh
Cell typeCylindricalCylindricalCylindricalCylindricalCylindricalCylindrical
ChemistryLiFePo4LiFePo4LiFePo4LiFePo4LiFePo4LiFePo4
Capacity per cell6,05 Ah6,05 Ah6,05 Ah6,05 Ah6,05 Ah6,05 Ah
Nominal voltage per cell3,2 V3,2 V3,2 V3,2 V3,2 V3,2 V
Cell configuration4s22p4s44p8s22p8s44p16s22p16s44p
Battery12V 1700Wh12V 3400Wh24V 3400Wh24V 6800Wh48V 6800Wh48V 13600Wh
On-off switchYesYesYesYesYesYes
TerminalsM8 screw FM8 screw FM8 screw FM8 screw FClickClick
Cell balancing, passiveYesYesYesYesYesYes
High current & short circuit protectionYes, up to 1500AYes, up to 1500AYes, up to 1500AYes, up to 1500AYes, up to 1500AYes, up to 1500A
Deep discharge protectionYesYesYesYesYesYes
Protection against polarity reversalYesYesYesYesYesYes
Individual cell string voltage monitoringYesYesYesYesYesYes
Safety vent for each cellYesYesYesYesYesYes
Cell temperature monitoringYesYesYesYesYesYes
Temp. monitoring battery electronicsYesYesYesYesYesYes
Shipping classificationUN3480, CLASS 9UN3480, CLASS 9UN3480, CLASS 9UN3480, CLASS 9UN3480, CLASS 9UN3480, CLASS 9
Certifications/compliance batteryCE, UN38.3, RoHSCE, UN38.3, RoHSCE, UN38.3, RoHSCE, UN38.3, RoHSCE, UN38.3, RoHSCE, UN38.3, RoHS
Certifications/compliance battery cellsUL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3UL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3UL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3UL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3UL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3UL, CE, IEC62133, IEC62619, IEC61960, BIS, PSE, RoHS, UN38.3
Battery12V 1700Wh12V 3400Wh24V 3400Wh24V 6800Wh48V 6800Wh48V 13600Wh
Cycle lifetime with 80% discharge depth at 25°C to capacity loss of 20% at 0.5C>4000>4000>4000>4000>4000>4000
Average annual capacity loss at 25 °C2%2%2%2%2%2%
Ideal storage temperature-10 up to 30 °C-10 up to 30 °C-10 up to 30 °C-10 up to 30 °C-10 up to 30 °C-10 up to 30 °C
